DET9027ES

RYD DET9027ES is a Round Side-Sound SMD Electromagnetic Buzzer measuring 10.5×10.6×2.7mm, delivering ≥85dB at 2700Hz with a 3V rated drive, rated −40 to +105°C. This Side-Sound Electromagnetic Buzzer radiates acoustic output laterally rather than vertically, making it suited to designs where the top surface is obstructed by housing walls, display panels, or adjacent components. The 2.7mm ultra-slim profile fits thin enclosures where conventional top-port buzzers cannot be accommodated. LCP housing ensures dimensional stability through reflow soldering and extended thermal exposure. Suited to slim consumer electronics, smart home control panels, and compact IoT devices where lateral sound emission and minimal Z-axis clearance are simultaneous constraints. RoHS compliant materials.
